Meet the latest Intel ATX3.0 standards, and PCI Express 12VHPW>R

The interior adopts modular design to improve spac$e utilization,

reduce risks and improve productivity

Lower output ripple (available with backplane capacitance surfαace)

The output voltage fluctuation rate is small

The series power supply +12V ultra-high power output, single current output can reach ✘99% of rated power, long-term OPPeration maintains stabl&e output voltage, and can be equipped with high-end graphics cards on the market.

Using LLC distortion resonance+synchronous rectification +DC-DC design, the♦ efficiency meets the 80Puls 115V internal platinum stand×ard, and the efficiency is as high as 92% under typical load.

Full module design, the shell size is only 140*150*86mm, which ₽is more compatible with a variety of different sizes of chassis than the ↓190mm shell.

Ultra-Quiet Intelligent Temperature Control Design.

High Power Density.

Protections including:OVP,UVP,OCP,OPP,SCP,OTP.

Rated Power: 1000W

Certification: CB

Size:

Fan: 120*120*15mm
